Xerox Phaser 6300 - Page 426

Parts List 9-5
Parts List 1.1 Covers - Service Parts List
No. Part Number Name/Description
1.
116-1964-00 Cover Assy Top (with 2,3)
2. Cover, Top
3. 116-2044-00 Cover Top Stopper
4. 116-1965-00 Cover Top Main
5. 333-4419-00
333-4424-00
Control Panel, Phaser 6300
Control Panel, Phaser 6350
6. 116-1966-00 Cover Assy Front (with 7)
7. Lever Out
8. 116-1967-00 Cover Assy Top (Door C) Imaging Unit (with 9~16)
9. Spring L/R
10. Plunger
11. Cover Top Phd
12. Latch Top L
13. Shaft Latch
14. Latch Top Ir R
15. Latch Top R
16. Spring Stopper Bottom
17. Cover Assy Rear (with 18,19)
18. 116-1968-00 Cover Rear
19. 116-1969-00 Fan Rear
20. 116-1970-00 Cover Side Right
21. Stud Top
22. 116-1971-00 Cover Front Right
23. 116-1972-00 Tray 1 (MPT) Base
24. Part of Tray
Holder Kit
Holder Tray Right
25. 116-1973-00 Tray 1 (MPT) (with 26, 27)
26. Tray 1 (MPT) Slide
27. Cover Tray 1 (MPT)
28. 116-1974-00 Cover Front Left
29. Part of Tray
Holder Kit
Holder, Tray Left
30. 116-1975-00 Cover Side Left
