10-14 Phaser 6300/6350 Color Laser Printer Service Manual
Denotes the function, and logic value of the signal when
the function operated (Low: L, High: H).
The given voltage is for signal in high status.
The arrow indicates the direction of signal.
Denotes a connection between wires.
Denotes a Clutch or Solenoid.
Denotes a Motor.
Denotes a photo sensor.
I/L +24VDC Denotes DC voltage when the interlock switch in Engine
Control Board turns on.
+5VDC
+3.3VDC
Denotes DC voltage.
SG Denotes signal ground.
Symbol Description
EXIT SENSED(L)+3.3VDC
M
To Next Page
