2-32 Phaser 6300/6350 Color Laser Printer Service Manual
Imaging Unit.
s6300-050
Main Drive Assembl
y
Registration Clutch
Gear P1
Turn Clutch
Gear Idler Turn
Paper Pick Assembly
Registration Chute Assembly
Gear Turn
