2-36 Phaser 6300/6350 Color Laser Printer Service Manual
The position of the Chute Assembly Out gears is shown in the following figure.
Note
These gears are spared as part of the Chute Assembly Gear Kit PL5.4.99
s6300-051
Duplex Motor
Chute Assembly Out
Gear 52
Gear Exit / Duplex
Gear Exit / Duplex
Gear 40 / 66H
Gear 40 / 66H
Gear 41
Gear 41
Front
