2-46 Phaser 6300/6350 Color Laser Printer Service Manual
■ No Toner Sensors [Y] [M] [C] [K]
Detects level of toner at the mouth of each auger tube.
■ Toner Cartridge In Sensors [Y] [M] [C] [K]
Detects the presence of the Toner Cartridge in the holder.
■ CRUM Reader
Reads the information contained in the Toner Cartridge CRUM.
■ Toner Cartridges [Y] [M] [C] [K]
Individual Toner Cartridges containing a toner mixture.
■ Toner Motors [Y] [M] [C] [K]
The Toner Cartridge Holder Assemblies each contain a Toner Motor which drives
the Agitator in the Toner Cartridges and the Auger in the Toner Cartridge Holder,
supplying toner through the Auger Tube to the Developer Assembly.
Toner Cartridge Holder
Toner Motor
Gear
Toner Cartridge
Gear
Auger
Auger
Film Agitator
s6300-04
