Caution -
Remove the PCICS before removing the CMUL. Replacing the CMUL with
the PCICS installed may damage the PCICS or CMUL.
Caution -
Before removing the CMUL or CMUU, bundle the PCIe cables of the
CMUU in the specified procedure. Removing the CMUL or CMUU without bundling
the PCIe cables may damage the CMUL or CMUU.
For details, see "Chapter 17 Maintaining the CPU Memory Unit and Memory."
Caution -
Remove the XBU before removing the CMUL or CMUU from the SPARC
M12-2S. Replacing the CMUL or CMUU with the XBU installed may damage the
CMUL/CMUU or XBU.
Caution -
The CMUU weighs 10 kg (22 lb), and the CMUL weighs 13 kg (29 lb). Work
must be done by two people if the chassis is mounted at the 24U or higher position of
the rack. If the work is done by one person, it may result in an
injury or damage to
the chassis.
in green or off. If the READY LED of the XSCF is blinking, wait until the LED
stays lit or is turned off.
■
You cannot replace the master XSCFU. To replace it, switch the master, or remove
the power cords of all the BBs.
■
If you select the XSCFU in the replacefru command menu, you cannot remove the
XSCF DUAL control cable, XSCF BB control cable, or power cord. The only unit
that you can remove is the XSCFU.
■
During the XSCFU replacement, do not configure the various settings of XSCF
reboot, master switching, firmware update, physical partition power-on/power-
off/reset, and the XSCF. If any of these processes is in progress, wait for the
process to complete before replacing the XSCFU.
■
During the active replacement of the XSCFU, the ldm command may cause an
error in the control domain where the replacement is performed. Retry after the
replacement of the XSCFU is complete. After the replacement is complete, check
that the ldmd service in the control domain is running normally.
Precautions for CMU and memory replacement
■
When remounting memory during the replacement of the CMUL/CMUU or
memory, be sure to remount a memory module of the same capacity and the same
rank at the same location as before.
■
If you have replaced the CMUL that has the hardware RAID function enabled,
re-enable the hardware RAID volume.
For details, see "14.2.11 Re-enabling a Hardware RAID Volume" in the Fujitsu
SPARC M12 and Fujitsu M10/SPARC M10 System Operation and Administration
Guide.
Fujitsu SPARC M12-2/M12-2S Service Manual
･
January 2023228
