Fujitsu Oracle SPARC M12-2 User Manual

Table 9-9
Procedure for Dynamically Releasing a PCIe Card
Step Operation Description Execution Location Command Used
1 Checking the mounting location of the
target PCIe card (Ap_Id)
Control domain
Root domain
# cfgadm -a
2 Releasing the target PCIe card from the
Oracle Solaris device configuration
Control domain
Root domain
# cfgadm -c unconfigure <Ap_Id>
3 Powering off the PCIe card slot that
houses the PCIe card released from the
device configuration
Control
domain
Root domain
# cfgadm -c disconnect <Ap_Id>
4 Confirming that you can remove the
target PCIe card
Control domain
Root domain
# cfgadm -a
5 (*1) Having the ATTENTION LED (amber)
of the PCIe card slot housing the target
PCIe card blink
Control domain
Root domain
# cfgadm -x led=attn,mode=blink <Ap_Id>
6 (*2) Turning off the
ATTENTION LED on
the PCIe card slot by mounting the
PCICS from which the PCIe card was
removed
Control domain
Root domain
# cfadm -x led=attn,mode=off <Ap_Id>
*1 Before removing the PCICS from the PCI slot, check the PCIe card slot to see that the POWER LED is off and that the ATTENTION
LED (amber) is blinking.
*2 When replacing a PCIe card, incorporate the PCIe card into the Oracle Solaris device configuration and then turn off the ATTENTION
LED. For details, see "Dynamically Configuring Devices" in the Managing Devices in Oracle Solaris for the Oracle Solaris version used, and
the man page of the cfgadm_pci command.
Note -
For the locations of the LEDs on PCIe card slots, see "PCIe card slot" in "2.4.3 LEDs of
Each Unit."
primary#
cfgadm -a
Ap_Id Type Receptable Occupant Condition
BB#0-PCI#0 pci-pci/hp connected configured ok
(Omitted)
primary#
cfgadm -c unconfigure BB#0-PCI#0
The following example executes the commands for enabling the removal of the PCIe
card mounted in PCI slot #0 of the SPARC M12 by using the PCI Hot Plug function.
1.
Check the status of the PCIe card to be removed.
The following example confirms that the PCIe card to be removed
using the
control domain is incorporated in the Oracle Solaris device configuration.
2.
Release the target PCIe card from the Oracle Solaris device configuration.
The following example releases the PCIe card mounted in PCI slot #0 from the
Oracle Solaris device configuration by using the control domain.
3.
Power off the PCIe card
released from the Oracle Solaris device configuration.
The following example powers off the PCIe card mounted in PCI slot #0 by using
Chapter 9 Releasing FRUs From the System 289
