*1 Select the BB-ID to be added. Here, select BB#2.
*2 To add the SPARC M12-2S, select "BB itself".
*3 Check that the SPARC M12-2S is not connected to BB#2.
*4 Enter "a" to start the operation of adding the SPARC M12-2S to BB#2.
*5 Do not enter anything until step 4 is
complete.
Note -
For information on the connection of the various cables, see "Appendix A Lists of
Cable Connections in a Building Block Configuration."
Please execute the following steps:
1) After the added device is connected with the system,
please turn on the breaker of the BB#2.
2) Please select[f:finish] :
f
←
(*6)
Waiting for BB#2 to enter install state.
[This operation may take up to 20 minute(s)]
(progress scale reported in seconds)
0..... 30..... 60.....
90..... 120..... 150..... 180..... 210.....
240..... 270..... 300..... 330..... 360..... 390..... 420..... 450.....
480..... 510..... 540..... 570..... 600..... 630. done
Waiting for BB#2 to enter ready state.
[This operation may take up to 45 minute(s)]
(progress scale reported in seconds)
0..... 30..... 60..... 90..... 120..... 150..... 180..... 210.....
240.... done
Do
you want to start to diagnose BB#2?[s:start|c:cancel] :
s
←
(*7)
Diagnostic tests for BB#2 have started.
Initial diagnosis is about to start, Continue?[y|n] :
y
←
(*8)
PSB#02-0 power on sequence started.
0..... 30....end
Initial diagnosis started. [1 / 2] [7200sec]
0..... 30..... 60..... 90.....120.....150.....180.....210.....240...../
4.
Connect the cables to the SPARC M12-2S to be added.
Connect the XSCF BB control cable and crossbar cable to the SPARC M12-2S to
be added. If the added SPARC M12-2S will operate as the standby XSCF, also
connect the XSCF DUAL control cable.
After connecting the XSCF BB control cable,
XSCF DUAL control cable, and
crossbar cable, connect the power cord and start the XSCF. When you have done
this, check that the READY LED on the XSCFU is blinking. For details, see the
part about the XSCF unit in "2.4.3 LEDs of Each Unit."
5.
Incorporate the SPARC M12-2S into
the building block configuration.
When you have the cables and power cord connected to the SPARC M12-2S to be
added and the READY LED blinking on the XSCFU, continue the operation of
step 3.
Note that incorporating the SPARC M12-2S into the building block configuration
makes the READY LED on the
XSCFU stay lit.
Chapter 10 Setting Up the System 335
