Fujitsu Oracle SPARC M12-2 User Manual

PCIe cable
Cable guide
Caution -
Hold the PCIe cables with both hands to carefully remove the cables from
the cable guide. If excessive force is used to pull out the PCIe cables, the cables may
break or the connectors may be damaged.
Caution -
Remove the PCIe cable connectors carefully. If you roughly remove them,
the PCIe cable may break or the connector may be damaged.
Figure 17-8
Removing the PCIe Cables From the Cable Guide
2.
Remove the PCIe cables from the CMUL.
The latch of the PCIe cable connector is located on the underside of the
connector. Pull out the connector by pinching the connector hood while pushing
the latch.
Chapter 17 Maintaining the CPU Memory Unit and Memory 443
