Note -
The XSCF DUAL control cable is connected only to the SPARC M12-2S that houses the
master XSCF or standby XSCF.
Caution -
When removing the XSCF DUAL control cable or XSCF BB control cable,
keep the latches on both sides of the connector hood pressed. Removing the cable
forcibly may damage it.
Figure 18-10
Removing the XSCF DUAL Control Cable/XSCF BB Control Cable
12.
Remove the XSCFU.
The XSCFU may have a LAN cable, a serial cable, and USB memory connected to
it. Remove them all. Then, loosen the fixing screws of the XSCFU, and remove
the XSCFU from the server. For details, see
"11.4 Removing the XSCFU."
Figure 18-11
Removing the XSCFU
Fujitsu SPARC M12-2/M12-2S Service Manual
･
January 2023470
