Caution
-
When
installing
the
PSUBP,
make
sure
that
it
is
kept
horizontal
and
perform
the
work
carefully.
Installing
the
PSUBP
while
it
is
tilted
may
damage
the
PSUBP
due
to
interference
from
the
BPU
components.
2.
Secure
the
PSUBP.
Tighten
the
three
fixing
screws
to
secure
the
PSUBP
to
the
BPU.
Figure
18-18
　　
Securing
the
PSUBP
3.
Connect
the
PSUBP
to
the
BPU.
There
are
two
connectors
that
connect
the
PSUBP
and
BPU.
Install
the
connector
(black)
shown
in
A
of
Figure
18-19
first
and
then
the
connector
(brown)
shown
in
B
of
Figure
18-19.
To
install
the
connector
shown
in
B
of
Figure
18-19,
insert
it
into
the
connector
slot
on
the
BPU
side,
with
the
latches
closed,
and
then
push
it.
Once
the
connector
is
secured,
the
latches
open.
Fujitsu
SPARC
M12-2/M12-2S
Service
Manual
･
January
2023476
