Caution
-
Do
not
pull
the
cable
when
connecting
a
connector.
The
cable
may
break.
Figure
18-19
　　
Connector
Connection
of
the
PSUBP
and
BPU
4.
Install
the
connector
cover.
Hold
the
tab
of
the
connector
cover
(A
in
Figure
18-20)
to
press
the
top
surface
(B
in
Figure
18-20)
and
the
right
ends
(C
in
Figure
18-20)
of
the
connector
cover
on
to
the
BPU.
Next,
tighten
the
fixing
screw
(D
in
Figure
18-20)
to
secure
the
connector
cover
to
the
BPU.
Chapter
18
　
Maintaining
the
Backplane
Unit
and
PSU
Backplane
Unit 477
