(1)
Number
in
Figure
Description
1 Pull-tab
Caution
-
When
connecting
the
crossbar
cable,
do
not
hold
the
pull-tab
but
hold
the
connector
part
to
insert
it
into
the
port
for
the
connection,
and
push
in
the
connector
part.
If
you
hold
the
pull-tab
when
connecting
the
crossbar
cable,
it
may
become
impossible
to
remove
the
cable
from
the
XBU.
Note
-
On
the
crossbar
box
side,
you
may
connect
the
crossbar
cables
with
the
power
on.
Caution
-
A
loose
crossbar
cable
connection
may,
on
rare
occasions,
cause
an
error
due
to
poor
connection.
After
connecting
a
crossbar
cable,
push
it
in
again
so
that
it
is
tightly
in
place
to
prevent
any
improper
connection.
Do
not
hold
only
the
cable
when
performing
the
work
at
this
time.
Otherwise,
the
cable
may
bend
out
of
shape.
Figure
19-10
　　
Crossbar
Cable
(Electrical)
Shape
and
Pull-Tab
3.
Bundle
the
crossbar
cables.
Bundle
the
crossbar
cables
with
the
hook-and-loop
fastener.
4.
Confirm
that
the
crossbar
cables
are
correctly
and
firmly
connected.
With
the
crossbar
cables
connected
to
their
ports,
push
in
each
cable
while
holding
the
joint
(A
in
Figure
19-11
and
Figure
19-12)
at
the
base
of
the
crossbar
cable
connector.
Fujitsu
SPARC
M12-2/M12-2S
Service
Manual
ï½¥
January
2023498
