16.6.5. Register definition
TIMER5 base address: 0x4000 1000
Control register 0 (TIMERx_CTL0)
Address offset: 0x00
Reset value: 0x0000 0000
This register has to be accessed by word (32-bit).
31
30
29
28
27
26
25
24
23
22
21
20
19
18
17
16
Reserved
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
0
Reserved
ARSE
Reserved
SPM
UPS
UPDIS
CEN
rw
rw
rw
rw
rw
Bits
Fields
Descriptions
31:8
Reserved
Must be kept at reset value.
7
ARSE
Auto-reload shadow enable
0: The shadow register for TIMERx_CAR register is disabled
1: The shadow register for TIMERx_CAR register is enabled
6:4
Reserved
Must be kept at reset value.
3
SPM
Single pulse mode.
0: Single pulse mode disable. The counter continues after update event.
1: Single pulse mode enable. The counter counts until the next update event
occurs.
2
UPS
Update source
This bit is used to select the update event sources by software.
0: These events generate update interrupts or DMA requests:
The UPG bit is set
The counter generates an overflow or underflow event
The restart mode generates an update event.
1: This event generates update interrupts or DMA requests:
The counter generates an overflow or underflow event
1
UPDIS
Update disable.
This bit is used to enable or disable the update event generation.
0: Update event enable. When an update event occurs, the corresponding shadow
registers are loaded with their preloaded values. These events generate update
event:
The UPG bit is set
The counter generates an overflow or underflow event
