IDEC SmartAXIS Touch FT1A Series

SmartAXIS Touch User’s Manual 9-35
2 Character Input
9
Data Displays
Example: If the user and security group for a part are set as follows:
For User 1, who is not included in the specified security group, Group A parts are not displayed.
If the Password Screen is now opened and a switch is made to User 2 of Group A, Group A parts are displayed.
Since the display security group is Group A, User 2 (of Group A) can view the buttons. But since the input security
group is Group B, User 2 cannot operate the buttons.
Suppose that the Password Screen is now opened and a switch is made to User 3, who is part of both Group A and
Group B. Group A buttons can be displayed, and Group B buttons can be operated.
■ No Touch Sound
This function is to disable touch sounds only for specified parts when the Touch makes touch sounds.
Select this check box to display disable touch sounds for this part.
User Name
Security Group None Group A Group A, Group B
User1
User2
User3
Touch
130
FT SERIES
Line Chart and Bar Chart
Display: Group A
Character Input
Display: Group A
Input: Group B
Numerical Display
Display: None
Open Password Screen,
enter password,
and switch to User2.
Group A parts are
not displayed to User1.
Group A parts are
displayed to User2.
Touch
Touch Touch
130
FT SERIES
User1 User2
130130
Password
ENT
 User2
********
BS CLR OK
A B C D E F G H I J K L M
N O P Q R S T U V W X Y Z
0 1 2 3 A 5 6 7 8 9
Open Password Screen,
enter password,
and switch to User3.
For User2,
Group A parts are displayed but
Group B parts cannot be operated.
For User3,
Group A parts are displayed and
Group B parts can be operated.
Touch
130
Touch Touch
130130
FT SERIES_
FT SERIES_
FT SERIES FT SERIES
User2 User3
ENT
BS CLR OK
Password
User3
********
A B C D E F G H I J K L M
N O P Q R S T U V W X Y Z
0 1 2 3 A 5 6 7 8 9
Button
Can operate
Button
Cannot operate
To enable touch sounds on the Touch, select the Enable Touch Sound check box on the System tab in
the Project Settings dialog box.
