1 USB Flash Drives
26-2 SmartAXIS Touch User's Manual
1.3 File Structure
When downloading or uploading data using the WindO/I-NV3, the following files and folders are accessible.
By default, the External Memory Folder on the external memory is named “HGDATA01”. For details, refer to “1.5
Setting the External Memory Folder” on page 26-12.
USB flash drive
HGDATA01 (External Memory Folder)
HGDATA02
HGDATA03
Folder name File name Description
ALARMLOG
[user-defined].CSV
Default file name
Batch: ALMHTO.CSV
Real time: ALMHTA.CSV
Alarm Log data
DATALOG
[user-defined].CSV
Default file name
Batch: LOGO**.CSV
Real time: LOGA**.CSV
Data Log data
(** corresponds to the data number)
OPERATIONLOG
[user-defined].CSV
Default file name
Batch: OPLOGO.CSV
Real time: OPLOGA.CSV
Operation Log data
RECIPE
[user-defined].CSV
Default: RCP****.CSV
Recipe data
(*** corresponds to the recipe
number)
NVDATA [Project name].ZNV Project files
Users can create multiple external memory folders for different projects on a single USB flash drive. Note,
the External Memory Folder on the external memory must reside on the root directory.
Do not alter project files (ZNV format). Altered files cannot be used with Touch.
