SmartAXIS Touch User’s Manual 17-3
1 Overview
17
Preventive Maintenance Function
1.3 Thresholds
The threshold is a value that is the criterion for reporting to a configured device (Report Device) when the value
counted for the operation time or operation count (the value of Operation Time Device or Operation Count Device)
has reached the threshold value. 1 is written to the configured device when the operation time and operation count
reach the threshold.
Example: When the value of Operation Time Device LKR0 reaches the threshold set for level 1 through level 3, 1 is
written to the Report Device configured for each level, LM1 through LM3.
Level Threshold Report Device
Level 1 10 LM1
Level 2 15 LM2
Level 3 20 LM3
1
0
1
0
1
0
Value of
Operation Time Device LKR0
Value of
Report Device LM1
Value of
Report Device LM2
Value of
Report Device LM3
Level 3
9 10111213141516171819202122
Level 1 threshold Level 2 threshold Level 3 threshold
Level 1
Level 2
To Next Page
