4 Using the Data
17-14 SmartAXIS Touch User’s Manual
4.2 Notifying with a Beep when the Counted Operation Time Reaches the Threshold
1 On the Configuration tab, in the System Setup group, click Preventive Maintenance.
The Preventive Maintenance Settings dialog box is displayed.
2 Specify the number of devices to monitor in Number of Items.
3 Select the number to register the Preventive Maintenance settings to in Settings, then click Edit.
The Individual Settings dialog box is displayed.
4 Specify the bit device or bit of the word device to monitor with Monitor Device.
5 Select the Measure Operation Time check box on the Operation Time tab and specify the destination device for
the counted operation time.
6 Select the data type for the value of the Measure Operation Time device from Data Type.
To Next Page
