1.5 Specifications
■ Applicable Standards
■ Environmental Specifications
■ Electrical Specifications
FT1A-*12RA
FT1A-*14KA/SA
■ Construction Specifications
*1 When using the Touch as the EMC Standard Approved Products, attach a ferrite core (ZCAT3035-1330 manufactured by TDK
Corporation) to the power cables and the communication cables.
If there a risk of an error occurring due to noise, install the product separated from sources of noise such as power lines,
high voltage lines, and load lines. Also attach a ferrite core to the I/O cable (ZCAT3035-1330 manufactured by TDK
Corporation).
*2 FT1A-*12RA-*: The UL and c-UL certified operating temperature is 0 to 50ºC.
Safety Standard
UL508
CSA C22.2 No.142 (c-UL)
EMC Standard
*1
IEC/EN 61131-2:2007
Operating Temperature
0 to 55°C: FT1A-M (Monochrome LCD models)
*2
(No freezing)
-20 to 55°C: FT1A-C (Color LCD models)
*2
(No freezing)
Relative Humidity 10 to 95% RH (No condensation)
Storage Temperature -20 to +60°C (No freezing)
Storage Humidity 10 to 95% RH (No condensation)
Altitude
Operation: 0 to 2,000m
Transport: 0 to 3,000m
Pollution Degree 2
Corrosion Immunity Free from corrosive gases
Rated Voltage 24V DC
Power Consumption 9.2W max. When USB2 is unused: 5.8W max.
Power Voltage Range 20.4 to 28.8V DC
Allowable Momentary Power
Interruption
10 msec max.
Inrush Current 50A max.
Dielectric Strength
Between power and FE terminals: 500V AC, 5mA,1 minute
Between power and output terminals: 2,300V AC, 5mA, 1 minute
Rated Voltage 24V DC
Power Consumption 10.1W max. When USB2 is unused: 8.1W max.
Power Voltage Range 20.4 to 28.8V DC
Allowable Momentary Power
Interruption
11 msec max.
Inrush Current 50A max.
Dielectric Strength
Between power and FE terminals: 500V AC, 5mA,1 minute
Between power and output terminals: 500V AC, 5mA, 1 minute
Vibration Resistance
5 to 8.4Hz amplitude 3.5mm, 8.4 to 150Hz acceleration 9.8m/s
2
10 times on each of three mutually perpendicular axes (100 minutes) (IEC61131-2)
Shock Resistance
147m/s
2
, 11ms (5 shocks on each of three mutually perpendicular axes)
(IEC61131-2)

IDEC SmartAXIS Touch FT1A Series Specifications

General

Brand	IDEC
Model	SmartAXIS Touch FT1A Series
Category	Controller
Language	English
