SmartAXIS Touch User’s Manual 7-95
7 Selector Switch
7
Buttons
7.2 Selector Switch Configuration Procedure
This section describes the configuration procedure for Selector Switch buttons.
1 On the Home tab, in the Parts group, click Buttons, and then click Selector Switch.
2 Click a point on the edit screen where you want to place the Selector Switch.
3 Double-click the dropped Selector Switch and a Properties dialog box will be displayed.
4 Change the settings on each tab as necessary.
The Trigger Condition tab and Options tab only appear in Advanced mode.
To switch to Advanced mode, click Advanced.
