IDEC SmartAXIS Touch FT1A Series User Manual

3 Configuration & Functions
2-42 SmartAXIS Touch User's Manual
3.3 Ribbon Command List
● Home
Home is where basic operations are performed such as creating a new screen, editing, and downloading project data.
■ Clipboard
■ Screens
■ Drawings
Command Description
Paste Pastes the contents of the clipboard.
Cut Cuts the selected object from the editing window and copies it to the clipboard.
Copy Copies the selected object to the clipboard.
Duplicate Duplicates the selected object.
Command Description
New
Base Screen Adds a new Base Screen.
Popup Screen Adds a new Popup Screen.
Library Screen Creates a new Library Screen.
Open
Base Screen Opens a Base Screen that has already been created.
Popup Screen Opens a Popup Screen that has already been created.
Library Screen Opens a Library Screen that has already been created.
Open Previous Screen Opens a screen number before the currently selected screen.
Open Next Screen Opens a screen number after the currently selected screen.
Delete Deletes the selected screen.
Reuse Copies another project’s screens.
Command Description
Shapes
Line Draws a line.
Polyline Draws a polyline.
Polygon Draws a polygon.
Rectangle Draws a rectangle.
Circle/Ellipse Draws a circle or ellipse.
Arc Draws an arc.
Pie Draws a pie.
Equilateral Polygons
Draws equilateral polygons (equilateral triangle, equilateral diamond, equilateral
pentagon, equilateral hexagon, equilateral octagon).
Fill
Fills the region with the same color as the fill start point with the specified color
and pattern.
Picture Inserts a picture.
Text Inserts text.
