2 Editing and Management of the Script
20-8 SmartAXIS Touch User’s Manual
2.3 Script Editor
A new script can be created or the script selected in Script Manager can be edited using Script Editor.
■ Script ID
To create a new script, enter the script ID (1 to 32,000).
To edit an existing script, the set script ID is displayed.
■ Script Name
Enter the script name. The maximum number for script name is 40 characters.
■ Data Type
Select the data type to be processed by the script.
For details about the data type, refer to “1.3 Data Type of the Script” on page 20-3.
■ Script
Enter the script.
Single script limitation is 240 characters per line with up to 1024 lines.
■ Error Check
The script being edited is checked for errors.
■ Import
The Open dialog box is displayed.
By selecting a script saved (exported) in a text format (*.txt) and clicking Open, the imported script is inserted at the
cursor position of the script being edited.
To Next Page
