7 Alarm Log Display
9-100 SmartAXIS Touch User’s Manual
7.2 Alarm Log Display Configuration Procedure
This section describes the configuration procedure for Alarm Log Display.
1 On the Home tab, in the Parts group, click Data Displays, and then click Alarm Log Display.
2 Click a point on the edit screen where you want to place the Alarm Log Display.
3 Double-click the dropped Alarm Log Display and a Properties dialog box will be displayed.
4 Change the settings on each tab as necessary.
The Options tab only appears in Advanced mode.
To switch to Advanced mode, click Advanced.
