IDEC SmartAXIS Touch FT1A Series

2 Analog Cartridge
29-30 SmartAXIS Touch User's Manual
2.4
Specifications
■ Analog Output Specifications
■ Analog Input Specifications
Type Number FC6A-PK2AV FC6A-PK2AW FC6A-PJ2A FC6A-PJ2CP
Rated Voltage 5.0 V, 3.3 V (Supplied from the Touch)
Consumption Current
5.0 V: 70 mA
3.3 V: 30 mA
5.0 V: 185 mA
3.3 V: 30 mA
5.0 V: -
3.3 V: 30 mA
5.0 V: -
3.3 V: 30 mA
Weight 15 g 15 g 15 g 15 g
Type Number FC6A-PK2AV FC6A-PK2AW
Output Type
Voltage Range 0 to 10 V -
Current Range - 4 to 20 mA
Load
Impedance 2 k min. 500  max.
Load Type Resistance load
D/A
Conversion
Cycle Time 20 ms 20 ms
Settling Time 40 ms max. 20 ms max.
Total Output System Transfer Time 60 ms+1 scan 40 ms+1 scan
Output Error
Maximum Error at 25°C ±0.3% of FS ±0.3% of FS
Temperature Coefficient ±0.02%/°C of FS ±0.02%/°C of FS
Reproducibility After Stabilization Time ±0.4% of FS ±0.4% of FS
Non-linearity ±0.01% of FS ±0.01% of FS
Output Ripple 30 mV max. 30 mV max.
Overshoot 0% 0%
Maximum Error ±1.0% of FS ±1.0% of FS
Data
Digital Resolution 4,096 increments (12bit) 4,096 increments (12bit)
LSB Output Value 2.44 mV (0 to 10 V) 3.91 µA (4 to 20 mA)
Data Format in Application 0···4095 (0 to 10 V) 0···4095 (4 to 20 mA)
Monotonicity Yes Yes
Open Current Loop - Cannot be detected
Noise
Resistance
Maximum Temporary Deviation
during Electrical Noise Tests
±4.0% of FS max. ±4.0% of FS max.
Recommended Cable Shielded twisted pair
Crosstalk 1 LSB max. 1 LSB max.
Isolation None None
Effect When Output is Incorrectly Wired No Damage No Damage
Calibration to Maintain Rated Accuracy Not possible Not possible
Type Number FC6A-PJ2A FC6A-PJ2CP
Input Type
Voltage
input
Current
input
Resistance thermometer Thermocouple
Input Range 0 to 10 V
4 to
20 mA
0 to
20 mA
Pt100:
-200 to +850 °C (-328 to 1562 'F)
Pt1000:
-200 to +600 °C (-328 to 1112 'F)
Ni100:
-60 to +180 °C (-76 to 356 'F)
Ni1000:
-60 to +180 °C (-76 to 356 'F)
(K)-200 to 1300 °C (-328 to 2372 °F)
(J)-200 to 1000 °C (-328 to 1832 °F)
(R)0 to 1760 °C (32 to 3200 °F)
(S)0 to 1760 °C (32 to 3200 °F)
(B)0 to 1820 °C (32 to 3308 °F)
(E)-200 to 800 °C (-328 to 1472 °F)
(T)-200 to 400 °C (-328 to 752 °F)
(N)-200 to 1300 °C (-328 to 2372 °F)
(C)0 to 2315 °C (32 to 4199 °F)
Input Impedance 1 M min. 250  max. 1 M min.
Allowable Conductor Resistance - - 10  max. -
Input Detection Current - - TYP: 0.2 mA 1.0 mA max. -
