SmartAXIS Touch User's Manual 29-31
2 Analog Cartridge
29
SmartAXIS Specifications
*1 The maximum amount of voltage value or current value that can be input without damaging the hardware.
AD
Conversion
Sample Duration
Time
10 ms
10 ms 250 ms 250 ms
Total Input System
Transfer Time
20 ms+1 scan
500 ms+1 scan
Type of Input Single-ended input
Operating Mode Self-scan
Conversion Method
SAR
Input
Error
Maximum Error at
25°C
±0.1% of FS
±0.1% of FS
±0.1% of FS
Cold junction compensation
accuracy ±4.0°C or less
Exceptions
R, S thermocouple error:
±6.0°C
(0 to 200°C range only)
B thermocouple error:
Not guaranteed
(0 to 300°C range only)
K, J, E, T, N thermocouple error:
±0.4% FS
(0°C or lower range only)
Temperature
Coefficient
±0.02%/°C of FS
±0.02%/°C of FS
Reproducibility After
Stabilization Time
±0.5% of FS
±0.5% of FS
Non-linearity ±0.01% of FS
±0.01% of FS
Maximum Error ±1.0% of FS
±1.0% of FS
Data
Digital Resolution
4,096 increments
(12bit)
Pt100: 10500 (14bit)
Pt1000: 8000 (13bit)
Ni100: 2400 (12bit)
Ni1000: 2400 (12bit)
K: 15000 (14bit)
J: 12000 (14bit)
R: 17600 (15bit)
S: 17600 (15bit)
B: 18200 (15bit)
E: 10000 (14bit)
T: 6000 (13bit)
N: 15000 (14bit)
C: 23150 (15bit)
LSB Input Value
2.44 mV
(0-10 V)
4.88 µA
(0 to
20 mA)
3.91 µA
(4 to
20 mA)
0.1°C
0.18'F
0.1°C
0.18'F
Data Format in
Application
Can be arbitrarily set for each channel in the range of -32,768 to 32,773
Monotonicity Yes
Noise
Resistance
Maximum Temporary
Deviation during
Electrical Noise Tests
±4.0% of FS max.
Recommended cable
Shielded twisted pair
Crosstalk 1 LSB max.
Isolation None
Effect When Input is
Incorrectly Wired
No Damage
Maximum Allowable Constant
Load *1(non-destructive)
13 V
40 mA 13 V
Input Type Modification Software programming
Calibration to Maintain Rated
Accuracy
Not possible
Type Number FC6A-PJ2A FC6A-PJ2CP
