SmartAXIS Touch User’s Manual 9-37
2 Character Input
9
Data Displays
2.4 How to Enter Text
Use the keypad or key buttons to write character codes to devices with the Character Input. The input methods are as
follows.
■ Pressing the Character Input and Entering Text from the Standard Keypad
Arrange a Character Input on the screen and in its properties dialog box, on the General tab, under Keypad, select
Standard for Type.
External device
Touch
FT
SERIE
FT
SERIES_
FT
FT_
FT SERIES_
FT SERIES
D100 :
4654
(Hex)
‘F’ ‘T’
D100 :
4654
(Hex)
‘F’ ‘T’
D100 :
D101 :
4654
(Hex)
‘F’ ‘T’
2053
(Hex)
4552
(Hex)
4945
(Hex)
5300
(Hex)
‘E’ ‘R’
D102 :
D103 :
D104 :
D100 :
D101 :
4654
(Hex)
‘F’ ‘T’
2053
(Hex)
4552
(Hex)
4945
(Hex)
5300
(Hex)
‘E’ ‘R’
D102 :
D103 :
D104 :
‘S’
(NULL)
‘ I ’ ‘E’
‘ ’ ‘S’
‘ I ’ ‘E’
‘S’
(NULL)
‘ ’ ‘S’
Press Character Input
Write text character
codes to devices
Press ENT
Display values of device as text
(Entry mode)
Display values of device as text
(Entry mode)
Close standard keypad
Display standard keypad
Enter text as
"FT SERIES"
Display values of device as text
(Display mode)
Display values of device as text
(Display mode)
When the following operations are performed, entry mode is canceled and the current values of devices are
displayed as character codes on the Character Input. To enter text, press the Character Input again to
select it and set it to entry mode.
• CAN is pressed.
•When the Focus is moved by ENT button check box on the General tab is cleared, a value was
written to the device by pressing ENT.
