SmartAXIS Touch User’s Manual A-11
6 Ladder Program
Appendix
6.5 Instruction Bytes
The quantities of bytes of basic and advanced instructions are listed below.
●
Basic Instruction
● Advanced Instruction
Basic
Instruction
Qty of Bytes
When not using
data registers
Using data
registers
LOD 4 8
LODN 4 8
OUT 4 8
OUTN 4 8
SET 4 8
RST 4 8
AND 4 8
ANDN 4 8
OR 4 8
ORN 4 8
AND·LOD 4
OR·LOD 4
BPS 4
BRD 4
BPP 4
SOTU 4
SOTD 4
TML 8
TIM 8
TMH 8
TMS 8
TMLO 8
TIMO 8
TMHO 8
TMSO 8
CNT 8
CDP 8
CUD 8
CNTD 8
CDPD 8
CUDD 8
SFR 8
SFRN 8
CC= 8
CC>= 8
DC= 8
DC>= 8
MCS 4
MCR 4
JMP 4
JEND 4
END 4
Basic
Instruction
Qty of Bytes
When not using
data registers
Using data
registers
Advanced Instruction Qty of Bytes
NOP 4
MOV, MOVN 12 to 16
IMOV, IMOVN 16
IBMV, IBMVN 16 to 24
BMOV 12 to 16
NSET 12 to 1,540
NRS 12 to 20
XCHG 12 to 16
TCCST 12 to 16
CMP (=, <>, <, >, <=, >=)
16 to 24
ICMP>= 16 to 28
LC (=, <>, <, >, <=, >=)
12 to 20
ADD, SUB, MUL, DIV 16 to 24
INC, DEC 8
ROOT 12 to 20
SUM 16 to 20
ANDW, ORW, XORW 16 to 24
SFTL, SFTR 12
BCDLS 12 to 16
WSFT 12 to 20
ROTL, ROTR 12
HTOB, BTOH 12 to 16
HTOA 12 to 20
ATOH 12 to 20
BTOA 12 to 20
ATOB 12 to 20
ENCO 12 to 16
DECO 12 to 16
BCNT 12 to 20
ALT 8
CVDT 12 to 20
DTDV 12 to 16
DTCB 12 to 16
SWAP 12 to 16
Advanced Instruction Qty of Bytes
