SmartAXIS Touch User’s Manual 19-15
3 Text Manager
19
Text Group
3.2 Text Group Settings Dialog Box
The groups for switching text are managed in the Text Group Settings dialog box.
■ Number of Text Groups
Specifies the number of text groups (1 to 16). The configured number of text groups are created.
■ Text Group Name
Enters the names of the text groups.
The maximum number for the Text Group name is 20 characters.
■ Default Group
Select the group to use when the Touch power is turned on and when switching to run mode.
■ Use Dynamic Text
Select this check box to switch the text group according to the value of device.
Specify the word device to use as the condition to switch the text group.
Click to display the Device Address Settings dialog box. For the device address configuration procedure, refer to
Chapter 2 “5.1 Device Address Settings” on page 2-62.
These options can only be configured when Number of Text Groups is specified as two or more.
When the value of device is 0, the text group switches to the text group set as the default group.
If the value of device is invalid, the text group is not switched.
To Next Page
