IDEC SmartAXIS Touch FT1A Series User Manual

7 FBD Program
A-14 SmartAXIS Touch User’s Manual
7.4 FB Execution Time
Group Name Symbol Device and Condition Execution time (μsec)
Logical
Operation
Logical AND AND  73.0
Negative Logical AND NAND  73.2
Logical OR OR  73.2
Negative Logical OR NOR  73.0
Exclusive Logical OR XOR  72.6
Negative Exclusive Logical
OR
XNOR  72.8
Negation NOT  70.8
Shot Up SOTU  72.6
Shot Down SOTD  72.8
Truth Table TRUTH  73.4
Timer
On-delay Count Up Timer TIMU  74.8
On-delay Count Down
Timer
TIMD  74.6
Off-delay Count Up Timer TIMOU  75.0
Off-delay Count Down
Timer
TIMOD  75.0
On/off-delay Timer TIMCU  77.4
Single Shot Pulse SPULS  74.8
Dual Timer DTIM  72.2
Random Pulse Output RPULS  95.2
Counter
Adding Counter CNT
W (Word) 75.0
D (Double word) 152.0
Up/Down Selection
Reversible Counter
CUD
W (Word) 75.6
D (Double word) 126.8
Hour Meter HOUR  94.6
Shift Register Shift Register SFR  50.8
Data
Comparison
Data Comparison CMP  82.0
Schmitt Trigger STTG  79.8
Range Comparison RCMP  81.6
Data Conversion Alternate Output ALT  59.2
Week
Programmer
Weekly Timer WEEK  112.8
Yearly Timer YEAR
 1
13.6
Script Script SCRPT 
Special
High-speed Counter HSC  159.0
RS Flip-flop RSFF  53.2
