SmartAXIS Touch User’s Manual 9-39
2 Character Input
9
Data Displays
2.6 Advanced Usage
● Using the System Area
• When finished entering text by pressing ENT, 1 is written to the System Area 2 Character Input setting complete bit
(address+3, bit 5).
• When CAN is pressed, entry mode is canceled and 1 is written to the System Area 2 Character Input setting cancel
bit (address+3, bit 6). However, if the keypad is closed by pressing (close) on the Popup Screen's title bar or
another Character Input is pressed and selected before finished entering the text by pressing ENT, entry mode is
canceled and 1 is not written to the System Area 2 Character Input setting cancel bit (address+3, bit 5).
• To clear the System Area 2 Character Input setting complete bit or the Character Input setting cancel bit, write 1 to
System Area 1 Character Input setting clear bit (address+1, bit 11). To automatically clear these bits when the
Character Input keypad is pressed in entry mode, select the Clear Keypad bit in System Area automatically
check box on the System tab in the Project Settings dialog box.
