SmartAXIS Touch User’s Manual 9-71
5 Message Switching Display
9
Data Displays
5.2 Message Switching Display Configuration Procedure
This section describes the configuration procedure for Message Switching Displays.
1 On the Home tab, in the Parts group, click Data Displays, and then click Message Switching Display.
2 Click a point on the edit screen where you want to place the Message Switching Display.
3 Double-click the dropped Message Switching Display and a Properties dialog box will be displayed.
4 Change the settings on each tab as necessary.
The Options tab only appears in Advanced mode.
To switch to Advanced mode, click Advanced.
