8 Potentiometer
7-110 SmartAXIS Touch User’s Manual
8.2 Potentiometer Configuration Procedure
This section describes the configuration procedure for Potentiometer parts.
1 On the Home tab, in the Parts group, click Buttons, and then click Potentiometer.
2 Click a point on the edit screen where you want to place the Potentiometer.
3 Double-click the dropped Potentiometer and a Properties dialog box will be displayed.
4 Change the settings on each tab as necessary.
The Trigger Condition tab and Options tab only appear in Advanced mode.
To switch to Advanced mode, click Advanced.
