IDEC SmartAXIS Touch FT1A Series

4 Creating and Deleting Data for Recipes
18-14 SmartAXIS Touch User’s Manual
4.1 Editing Recipe Data
You can export recipe data for the selected channel, edit the recipe values in a saved file, and import a recipe file
back into WindO/I-NV3.
1 On the Configuration tab, in the System Setup group, click Recipe.
The Recipe Settings dialog box is displayed.
2 Select the channel number to export its recipe data in Settings, and then click Edit.
The Individual Settings dialog box is displayed.
3 Click the Data tab, and then click Export.
The Save As dialog box is displayed.
4 Creating and Deleting Data for Recipes
