SmartAXIS Touch User’s Manual 20-7
2 Editing and Management of the Script
20
Script
2.2 Script Manager
Script Manager can add, delete and manage the script created by Script Editor.
■ Script List
Displays a list of registered scripts.
■ Script
Displays the contents of the script selected in the script list.
■ Add
Displays the Script Editor dialog box to add a script.
For details, refer to “2.3 Script Editor” on page 20-8.
■ Edit
Displays the Script Editor dialog box to allow editing of the selected script. For details, refer to “2.3 Script Editor” on
page 20-8.
■ Delete
Deletes the script selected in the script list.
If a script is used in a project or parts, it cannot be deleted.
■ Reduce
Deletes the scripts that are registered in the script list but are not used in the project.
■ Select
The highlighted script in the script list is selected and Script Manager is closed.
■ Close
Closes Script Manager.
Script ID: Displays the script ID (1 to 32,000) of the registered scripts.
Error: OK is displayed when there is no error in the registered script and NG is displayed when there is an error.
Script Name: Displays the script name of the registered scripts.
When Close is clicked after a change has been made in the script list, a confirmation message to save is
displayed. The change will be saved when OK is clicked. The change will be discarded and Script Manager
closed when Cancel is clicked.
To Next Page
