SmartAXIS Touch User’s Manual 15-17
4 Using the Data
15
Operation Log Function
4.1 Saving the Data as a CSV File
● Saving the Data as a CSV File
The Operation Log data can be saved to the external memory as a CSV file.
The procedure to save the data is as follows.
On the WindO/I-NV3 Configuration tab, click Operation Log to display the Operation Log Settings dialog box.
Select an output method check box on the External Memory tab and configure the items. The Operation Log data
is saved to the External Memory Folder on the external memory according to the External Memory tab settings. For
details, refer to “External Memory Tab” on page 15-14.
●
Data Structure and Output Example
The data structure of the output file is as follows. The data structure for files output with batch output and real time
output is the same.
Bold items are replaced by the Operation Log settings, recorded data, project file name, and WindO/I-NV3 version.
4 Using the Data
Files saved to external memory are read using WindO/I-NV3.
On the WindO/I-NV3 Online tab, click the arrow under Upload, and then click Data in external memory
to display the Upload from external memory dialog box. Select the Operation Log Data check box, specify
the location to save the files in Path, and then click OK to be able to save the files in the specified folder.
Headers
"Project Name","Project name","Version number"
"File Type","Log type"
Blank row
Label row
"Sampling Time","User Name","Screen No.","Event Name","Part Name","Device
Address","Changed to"
Data row
" MM/DD/YYYY HH:MM:SS","User Name","Screen Type & No.","Event","Part
Name","Device Address", "Changed to"
･
･
･
Output example
Data size of each row
"Project Name","Dimmer Console","V1.00" - 41 bytes
"File Type","Operation Log Data" - 34 bytes
- 2 bytes
"Sampling Time","User","Screen No.","Operation","Part Name","Details","Changed to" - 84 bytes
" 12/01/2011 12:00:10","-","Base 1","Power ON","-","-","-" - 60 bytes
" 12/01/2011 12:01:23","User1","Base 1","Switch to Base Screen","-","-", "Base2" - 81 bytes
·
·
·
• The data size for each row is counted as 2 bytes for full-width characters, one byte for half-width
characters, and two bytes for newlines. The total for each row is the total amount of space for the file.
• A space is inserted before the date in the data row.
• The display type for the date and time varies based on the language configured in Project Settings, on
the Project Details tab, in Language.
Japanese: YYYY/MM/DD HH:MM:SS
European, Chinese, Taiwanese, Korean, Central European, Baltic, Cyrillic: MM/DD/YYYY HH:MM:SS
