SmartAXIS Touch User’s Manual 13-25
4 Using Data and Detected Alarms
13
Alarm Log Function
4.1 Displaying Saved Data with the Alarm Log Display
1 On the Configuration tab, in the System Setup group, click Alarm Log.
The Alarm Log Settings dialog box is displayed.
2 Select the type of device to monitor under Source Device Type on the Channel tab and specify Number of
Blocks.
3 Select the channel number to register, and then click Edit.
The Individual Settings dialog box is displayed.
4 Specify the device to monitor in Source and select Store under Data.
4 Using Data and Detected Alarms
To Next Page
