IDEC SmartAXIS Touch FT1A Series User Manual

1 Bar Chart
10-2 SmartAXIS Touch User’s Manual
1.2 Bar Chart Configuration Procedure
This section describes the configuration procedure for bar charts.
1 On the Home tab, in the Parts group, click Charts, and then click Bar Chart.
2 Click a point on the edit screen where you want to place the Bar Chart.
3 Double-click the dropped Bar Chart and a Properties dialog box will be displayed.
4 Change the settings on each tab as necessary.
The Data Over tab, Scale tab, Trigger Condition tab and Options tab only appear in Advanced mode.
To switch to Advanced mode, click Advanced.
