1.3 Sampling Data
Data is sampled each time the alarm occurs, is recovered from, or confirmed.
Example: When the message for channel number 1-1 is “Voltage drop” and the message for channel number 1-2 is
“Temperature abnormal”
1
Channel No. 1-1: Alarm occurred Ch.No. Message Occurrence Time Recovery Time Confirmation Time
(12:50:00) 1-1 Voltage drop 12/01/2011 12:50:00 ––
Channel No. 1-2: No alarm
2
Channel No. 1-1: Alarm Ch.No. Message Occurrence Time Recovery Time Confirmation Time
(12:50:00) 1-1 Voltage drop 12/01/2011 12:50:00 ––
Channel No. 1-2: Alarm occurred
1-2
Temperature
abnormal
12/01/2011 12:50:10
––
(12:50:10)
3
Channel No. 1-1:
Recovered from
alarm
Ch.No. Message Occurrence Time Recovery Time Confirmation Time
(12:50:20) 1-1 Voltage drop 12/01/2011 12:50:00 12/01 12:50:20 –
Channel No. 1-2: Alarm
1-2
Temperature
abnormal
12/01/2011 12:50:10
––
(12:50:10)
4
Channel No. 1-1: CHECK pressed Ch.No. Message Occurrence Time Recovery Time Confirmation Time
(12:50:30) 1-1 Voltage drop 12/01/2011 12:50:00 12/01 12:50:20 12/01 12:50:30
Channel No. 1-2: Alarm
1-2
Temperature
abnormal
12/01/2011 12:50:10
––
(12:50:10)
5
Channel No. 1-1: Alarm occurred Ch.No. Message Occurrence Time Recovery Time Confirmation Time
(12:51:00) 1-1 Voltage drop 12/01/2011 12:50:00 12/01 12:50:20 12/01 12:50:30
Channel No. 1-2: Alarm
1-2
Temperature
abnormal
12/01/2011 12:50:10
––
(12:50:10)
1-1
Voltage drop 12/01/2011 12:51:00 ––
6
Channel No. 1-1: Alarm Ch.No. Message Occurrence Time Recovery Time Confirmation Time
(12:51:00) 1-1 Voltage drop 12/01/2011 12:50:00 12/01 12:50:20 12/01 12:50:30
Channel No. 1-2: CHECK pressed
1-2
Temperature
abnormal
12/01/2011 12:50:10
– 12/01 12:52:10
(12:52:10)
1-1
Voltage drop 12/01/2011 12:51:00 ––
7
Channel No. 1-1: Alarm Ch.No. Message Occurrence Time Recovery Time Confirmation Time
(12:51:00) 1-1 Voltage drop 12/01/2011 12:50:00 12/01 12:50:20 12/01 12:50:30
Channel No. 1-2:
Recovered from
alarm
1-2
Temperature
abnormal
12/01/2011 12:50:10 12/01 12:53:00 12/01 12:52:10
(12:52:10)
1-1
Voltage drop 12/01/2011 12:51:00 ––
