4 Clear
23-24 SmartAXIS Touch User's Manual
4.2 Deleting Data from an External Memory Inserted in the Touch
1 Change communication settings according to the connection method between the computer and the Touch.
In the Communication Settings dialog box, select Touch from Communicate with. To communicate with the Touch
as an O/I Link Slave via an O/I Link Master, select O/I Link Slave. For details, refer to “1.3 Change Communication
Settings” on page 23-5.
2 Open project data.
3 On the Online tab, in the Touch group, click Clear, then click Stored Data in External Memory.
The Clear Data dialog box is displayed.
4 Select the check box for the data items to be deleted from the External Memory Folder.
Alarm Log Data, Data Log Data, Operation Log Data, and Recipe Files
5 Click OK.
• When Communicate with is set to Touch and Port to USB, deletion of the data starts.
• When Communicate with is set to Touch and Port is set to Ethernet, the Target IP Address dialog box is
displayed. Specify the IP address of the Touch, and then click OK to start deletion of the data. For details, refer to
“To execute any function except project data download” on page 23-8.
• When Communicate with is set to O/I Link Slave, the Target Slave dialog box is displayed. Specify the slave
station of the Touch to communicate with, and then click OK to start deletion of the data.
If Port is set to Ethernet, specify the IP address of the master to be used. For details, refer to “To execute any
function except project data download” on page 23-9.
If security is enabled in the Touch project, the Password Screen is displayed. Enter the password.
For details, refer to Chapter 21 “User Accounts and the Security Function” on page 21-1.
To Next Page
