SmartAXIS Touch User’s Manual 8-15
2 Multi-State Lamps
8
Lamps
2.2 Multi-State Lamp Configuration Procedure
This section describes the configuration procedure for Multi-State Lamps.
1 On the Home tab, in the Parts group, click Lamps, and then click Multi-State Lamp.
2 Click a point on the edit screen where you want to place the Multi-State Lamp.
3 Double-click the dropped Multi-State Lamp and a Properties dialog box will be displayed.
4 Change the settings on each tab as necessary.
The Options tab only appears in Advanced mode.
To switch to Advanced mode, click Advanced.
