3 Project Settings Dialog Box
3-40 SmartAXIS Touch User's Manual
3.8 External Memory Tab
The External Memory tab is used to configure the destination folder on the external memory inserted in the Touch.
■ External Memory Folder
Enter the folder name for the folder in the external memory to use on the Touch within 8 alphanumeric characters
using upper-case alphabetic characters (A to Z) and numbers (0 to 9). The default External Memory Folder name is
“HGDATA01” .
All the data sampled with the log functions is saved in this External Memory Folder. For details on the external
memory, refer to Chapter 26 “1 USB Flash Drives” on page 26-1.
■ Remove Files
Select this check box to erase the files saved in the External Memory Folder.
• You cannot use the following characters in the folder name.
\ / : , ;* ? “ < > |
• After operation starts, the folders created in the External Memory Folder and the file names cannot be
changed.
All Alarm Log files: Select this check box to erase all the Alarm Log data saved in folder. The folder name is
"ALARMLOG".
All Data Log files: Select this check box to erase all the Data Log data saved in folder. The folder name is
"DATALOG".
All Operation Log files:
Select this check box to erase all the Operation Log data saved in all folders. The folder
name is "OPERATIONLOG".
Trigger Device: Specifies the bit device or bit of the word device to serve as condition to delete the files.
Click to display the Device Address Settings dialog box. For the device address
configuration procedure, refer to Chapter 2 “5.1 Device Address Settings” on page 2-62.
To Next Page
