IDEC SmartAXIS Touch FT1A Series User Manual

SmartAXIS Touch User's Manual 3-39
3 Project Settings Dialog Box
3
Project
■ Protocol
Shows the Protocol defined as the selected user communication.
■ Command
Shows the command settings for the selected Protocol. Double clicking the cell displays the Data Settings dialog box.
No.: Shows the number for managing the Protocol settings. Double clicking the cell displays the
Command Settings dialog box.
Type: Shows the type of command. Double clicking the cell displays the Command Settings dialog box.
Completed: Shows the send or receive complete report device. Double clicking the cell displays the
Command Settings dialog box.
Status: Shows the destination device for the send or receive size and error information. Double clicking
the cell displays the Command Settings dialog box.
Trigger Type: Shows the trigger type to execute the script. Double clicking the cell displays the Command
Settings dialog box.
Trigger Condition: The displayed content varies based on Trigger Type.
Rising-edge, Falling-edge, While ON, or While OFF: Shows the bit device that is the
condition. Double clicking the cell
displays the Command Settings
dialog box.
While satisfying the condition or Satisfy the
condition:
Shows the conditional expression.
Fixed Period:Shows the period.
Comment: Shows the command comment. Double clicking the cell displays the Command Settings dialog
box.
Size: Shows the command size in bytes. Double clicking the cell displays the Command Settings
dialog box.
