*1 The SCRPT instruction execution time is stored in D1+1 after the instruction is executed.
BTOH D→D 11.1
HTOA D→D 13.7
ATOH D→D6.0
BTOA D→D 13.7
ATOB D→D 56.3
ENCO M→Dbits=16 6.9
DECO D→M 50.0
BCNT M→Dbits=16 
ALT  42.7
CVDT
W, I, D, L→F 53.0
F→W, I, D, L 56.3
DTDV D→D8.9
DTCB D→D 10.4
SWAP (W)  8.9
SWAP (D)  89.7
WEEK 
YEAR 
LABEL 
LJMP 
LCAL 
LRET 
DJNZ 
IOREF  46.8
HSCRF  46.8
DI  90.3
EI  54.1
XYFS 
CVXTY 
CVYTX 
AVRG (W, I) S3=10 6.38
AVRG (D, L) S3=10 49.5
AVRG (F) S3=10 55.1
DTML, DTIM, DTMH  60.2
DTMS  63.0
TTIM  60.3
RAD F→F143.9
DEG F→F143.9
SIN, COS F→F161.1
TAN F→F1
49.1
ASIN, ACOS F→F618.9
ATAN F→F616.5
LOGE, LOG10 F→F206.0
EXP F→F172.5
POW F→F191.0
FIFOF  129.0
FIEX  129.0
Instruction
Device and
Condition
Execution
Time (μs)
FOEX  129.0
NDSRC (W, I) D, D, D→D19.5
NDSRC (D, L) D, D, D→D782.5
NDSRC (F) D, D, D→D782.5
TADD  54.4
TSUB  54.4
HOUR D→D, Y, D 20.6
HTOS  52.7
STOH D→D92.1
SCRPT 
*1
PID 
Instruction
Device and
Condition
Execution
Time (μs)
