SmartAXIS Touch User’s Manual 20-9
2 Editing and Management of the Script
20
Script
■ Export
The Save As dialog box is displayed.
By selecting a save location and clicking Save, the script being edited is saved in text format (*.txt). A saved script
can be inserted in the script clicking Import.
■ Options
The Options dialog box is displayed.
The fonts and color of the text, tab indents, etc., used in the Script text box are set in the Options dialog box. For
details, refer to “Script Formatting Options dialog box” on page 20-11.
■ Find
The Find dialog box is displayed.
Enter the text to be searched for in the Find What box.
■ Replace
The Replace dialog box is displayed.
Text entered in Find what will be replaced with the text entered in Replace with.
■ Show/Hide Function List
Switches between showing and not showing the Function List and Script Compilation Output.
■ Cursor
Displays the current position of the cursor in the Script text box by line number and column number.
When Find is clicked after selecting a range in the Script text box, it will only search within the selected
range.
• This is useful when replacing device addresses.
•When Replace is clicked after selecting a range in the Script text box, it will only search and replace
within the selected range.
The size of the script edit box can be changed by dragging the right bottom corner of the Script Editor. By
hiding the Function List and Script Compilation Output, the script editing area (text box) will become
larger, making the editing of script easier.
