SmartAXIS Touch User’s Manual 20-11
2 Editing and Management of the Script
20
Script
● Script Formatting Options dialog box
Font, Size, Tab indent, and Color used in the Script text box of the Script Editor can be specified.
■ Font
The font name for the text displayed in the Script is entered or selected.
■ Size
The font size (dots) for the text displayed in the Script is entered or selected.
■ Sample
Displays a sample of the text with the Font and Size as specified in the Script text box.
■ Tab indent
Specify the position of the indent when a tab is inserted (1 to 20).
■ Color
Displays each of the text colors for Comment, Keyword, and Device.
The Color dialog box is displayed when the color button is clicked.
Text other than comment, keyword, or device is displayed in black.
