IDEC SmartAXIS Touch FT1A Series

SmartAXIS Touch User's Manual 29-15
1 Touch
29
SmartAXIS Specifications
■ Performance Specifications
■ EMC Specifications
*2 The backlight life refers to the time until the surface brightness reduces to a half after using continuously at room
temperatures.
*3 In high temperature environments battery life may be affected, so retention time may be reduced.
*4 The degree of protection for the operating section after the panel is attached. The compliance test has been passed, but this
is not a guarantee of operation in all environments.
Type Number FT1A-M (Monochrome LCD models) FT1A-C (Color LCD models)
Display
LCD Type STN Monochrome LCD TFT Color LCD
Display Colors 2 Colors (Black, White) 8 shades 65,536 Colors
Effective Display Area [mm] 87.59(W) × 35.49 (H) 88.92 (W) × 37.05 (H)
Display Resolution 240 (W) x 100 (H) pixels
View angle Left/Right/Top/Bottom: 45° Left/Right: 40°, Top: 20°, Bottom: 60°
Contrast Adjustment 32 levels –
Brightness of LCD only
White: 740 [cd/m
2
]
Red: 135 [cd/m
2
]
400 [cd/m
2
]
Brightness Adjustment 32 levels
Backlight
LED (White, Red)
Screen color: White, Pink, Red
LED (White)
Backlight Life
*2
50,000 hours nominal
Touch
Panel
Switch Type Analog Resistive Film
Operating Force 0.2 to 2.5 N
Multiple Operations Impossible
Life 1,000,000 operations
User Memory 5MB
Backup Battery
*3
Lithium secondary battery
Backup Duration: Approx. 30 days (typical) (Operating temperature: 25°C)
Charging Time: Approx. 15 hours for charging from 0% to 90% of full charge
Battery Life: 5 years in cycles of 9-hour charging and 15-hour discharging
Replaceability: Not possible to replace battery
Backup Data 128KB
Buzzer Output Single tone (tone length is adjustable)
Degree of Protection
IP66F (IEC60529)
*4
Weight (approx.)
FT1A-*12RA: 300 g
FT1A-*14KA/SA: 250 g
Type Number FT1A-*12RA FT1A-*14KA/SA
Radiated Emission
Class A : 10m
40dBµV/m quasi-peak (30M to 230MHz)
47dBµV/m quasi-peak (230M to 1GHz)
Electrostatic Discharge
Contact : ±6kV
Air : ±8kV
Electromagnetic Field
10V/m (80 to 1000 MHz)
3V/m (1.4 to 2.0 GHz)
1V/m (2.0 to 2.7 GHz)
80% AM (1kHz)
Fast Transient Burst
±2kV (Power, Output terminal)
±1kV (Port, Ethernet, Input terminal)
±2kV (Power)
±1kV (Port, Ethernet, Input terminal,
Output terminal)
Surge Immunity
±500V (between +24V-0V)
±1kV (between +24V-FE, 0V-FE)
Conducted Radio
Frequency Immunity
10V (Power, Port, Ethernet, Input terminal, Output terminal)
(150kHz to 80MHz)
80% AM (1kHz)
