SmartAXIS Touch User’s Manual 17-15
4 Using the Data
17
Preventive Maintenance Function
7 Select the Report when Operation Time has reached or exceeded Threshold level check box.
8 Select the type of data for the threshold.
If you select Value, specify the threshold as a constant.
If you select Device, specify the threshold as a value of device.
9
Configure Threshold for level 1.
When you select Value as the threshold data type, specify the threshold as a constant. The range for the constant
that can be set varies based on the data type.
When you select Device as the threshold data type, specify the threshold as a value of device. Click to display the
Device Address Settings dialog box. For the device address configuration procedure, refer to Chapter 2 “5.1 Device
Address Settings” on page 2-62.
10
Configure Report Device for level 1.
Specify the bit device or bit of the word device for reporting when the threshold is reached or exceeded. Click to
display the Device Address Settings dialog box. For the device address configuration procedure, refer to Chapter 2
“5.1 Device Address Settings” on page 2-62.
You can only specify an internal device.
11
Click OK to close the Individual Settings dialog box.
12
Click OK to close the Preventive Maintenance Settings dialog box.
13
On the Configuration tab, in the System Setup group, click Alarm Log.
The Alarm Log Settings dialog box is displayed.
To Next Page
