EP80579 Integrated Processor Product Line—System Memory Interface (DIMM)
Intel
®
EP80579 Integrated Processor Product Line
Platform Design Guide May 2010
113 Order Number: 320068-005US
9.3 Rules for Populating DIMM Slots
Table 31 shows the supported DIMM population of the 2 ranks supported by the
EP80579. Configurations not shown in Table 31 are not supported. The rank
configurations supported are one or two ranks on a single DIMM or one rank on each of
the two DIMMs. Two ranks in each of the two DIMMs (that is, four ranks) is not
supported.
9.3.1 Supported Rank Configurations
Table 32 shows the supported rank configurations when using two ranks for the single
and dual DIMM.
.
Table 30. Supported DDR2 Data Speeds
DDR Speed
1 DIMM
1 rank
1 DIMM
2 ranks
2 DIMMs
1 rank each
DDR2-400
R = 1T
UB = 1T
R = 1T
UB = 1T
R = 1T
UB = 2T
DDR2-533
R = 1T
UB = 1T
R = 1T
UB = 1T
R = 1T
UB = 2T
DDR2-667
R = 1T
UB = 1T
R = 1T
UB = 1T
R = 1T
UB = 2T
DDR2-800
R = 1T
UB = 2T
R = 1T
UB = 2T
Not supported
R = Registered
UB = Unbuffered
1T = 1T Address/Command Timing
2T = 2T Address/Command Timing
Table 31. Supported DIMM Populations
DIMM1 DIMM0
Rank0 Rank1 Rank0 Rank1
1 - Single Rank Empty Empty CS0 Empty
1 - Dual Rank Empty Empty CS0 CS1
2 - Single Rank CS1 Empty CS0 Empty
TABLE KEY:
CS0/CS1: Chip Selects
Table 32. Supported DDR2 Rank Configurations in Single and Dual DIMM mode (Sheet 1
of 2)
Single DIMM
(64 bits - rank 0 & rank 1)
(32 bits - rank 0 only)
Dual DIMM
(64 bit only)
Rank 0 Rank 1 Rank 0, DIMM 1 Rank 0, DIMM 0
128 MB
(32 bit only)
NA NA NA
256 MB 256 MB 256MB
256 MB, 512 MB,
1GB, 2 GB
