Intel
®
EP80579 Integrated Processor Product Line—System Power Delivery Guide
Intel
®
EP80579 Integrated Processor Product Line
Platform Design Guide May 2010
66 Order Number: 320068-005US
6.3 Power Planes
Table 10 summarizes the Development Board power supply interconnect to the
EP80579 power pins.
Suspend
1.2V
VCC1P2_USBSUS USB2 1.2V USB sustain power
VCCSUS1 IMCH_PAD RTC core sustain power
2.5V VCCSUS25 GbE Sustain GbE power
3.3V
VCCPSUS USB2, IMCH
USB sustain power, RTC IO
sustain power
VCCGBEPSUS GbE
Sustain 3.3V tolerance
reference
5V VCC50_SUS N/A N/A
RTC 3.3V VCCPRTC IMCH Real Time Clock power
GND Analog Ground VSSA Ground Analog Ground
GND Ground VSS Ground Ground
Table 9. Power Supply Pins (Sheet 2 of 2)
Well
Development
Board
Voltage Rail
EP80579
Power Pin
Name
Supply Types Description
Table 10. Power and Ground Planes (Sheet 1 of 2)
Development
Board
Signal Name
EP80579
Power Pin Name
Description
IA-32 core Power Supply Pins
VCC_CPU VCCVC
Power Supply (1.0V - 1.3V) for IA-32 core
• 1.0V when operating at 600 MHz
• 1.3V when operating at 1.066 GHz
• 1.3V when operating at 1.2 GHz
VCCA[2:1] VCCA[2:1] 1.2V CPU core PLL Analog Voltage
Core Logic Power Supply Pins
V1P2 VCC
1.2V supply pins for core logic (CRU, EXP_Bus, GbE, IICH,
IMCH, SATA, PCI Express)
VCC3 VCC33
3.3V supply for all 3.3V I/O functions which are not dedicated
to their own power rail. The units using this rail include:
IMCH, Global Clock/Reset(CRU), USB, CAN, EXP_Bus, SATA,
and GbE.
VCC VCC50
5V power supply for 5V tolerance units. (IICH, CRU, CAN, and
EXP_Bus
V2P5 VCC25 2.5V supply for GbE unit.
DDR2 Unit Power Supply Pins
V1P8_DDR VCC18 1.8V power supply for DDR2 I/O
DDR2_VTT VTTDDR 0.9V DDR2 Reference Voltage (Vref)
Suspend/Resume Power Supply Pins
VSBY1_2
VCCSUS1
VCC1P2_USBSUS
1.2V power pins for the resume well GbE, USB, and IICH core
logic. This power is not expected to be shut off unless the
system is unplugged.
To Next Page
