Intel

EP80579 Integrated Processor Product Line—Component Quadrant Layout

Intel

EP80579 Integrated Processor Product Line

Platform Design Guide May 2010

37 Order Number: 320068-005US

4.0 Component Quadrant Layout

Figure 5 and Figure 6 show only general quadrant information for the EP80579

component, and not exact component pin placement. Designers must use the exact pin

assignment to conduct routing analysis. See the Intel

EP80579 Integrated Processor

Product Line Datasheet for exact ball assignment information.
